Highshield ESD shielding bubble wrap, 600 mm wide, 100 m roll - Warmbier 3350.394

On the road, populated assemblies need two things at once: mechanical cushioning and protection from electrostatic fields. This cushion material provides both - the air pockets absorb shocks, while the three-layer structure with its Highshield outer layer keeps the energy of a discharge below 5 nJoule.

Benefits

• Shielding rather than merely dissipative: residual discharge energy stays below 5 nJoule, so goods stay protected outside the EPA.
• Three-layer structure with a smooth Highshield outer face and a smooth Permastat inner face, the product rests on a dissipative surface.
• Typical bleeder resistance of 10^9 to 10^10 Ohm, charges drain in a controlled way instead of all at once.
• Weldable, so pouches and cushions are made from the web in the size a job calls for.
• Roll 600 mm wide and 100 m long, which is 60 m² of material per sales unit.
• Recyclable.

Application

Cushioning for boards, modules and spare parts in shipping cartons, interlayers in transport containers, cut pieces for moves between two EPA workstations. Whenever populated electronics leave the protected area, the shielding grade is the correct choice.
