ESD PCB magazine 602.1, polystyrene side walls, PCB width 10-250 mm, 320 x 400 x 563 mm - cab 8917602

cab ✓ Original product Brand new

ESD PCB magazine from the cab 600 series for PCBs 10-250 mm wide and up to 387 mm long. Side walls made of polystyrene, guides rated up to 60 °C. External dimensions 320 x 400 x 563 mm, stackable, with transport lock.

Net
€284.35
excl. VAT
Item WL22201
Manufacturer no. 8917602
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Populated and bare PCBs have to be buffered, transported and handed over to SMT lines safely between production steps. This magazine holds PCBs 10-250 mm wide and up to 387 mm long, with guides withstanding up to 60 °C. On the 600 series, the side wall is set to the PCB width via four screw clamps - the cost-effective variant for lines with rarely changing formats.

Benefits

  • PCB width continuously adjustable, 10-250 mm
  • Width adjustment: screw clamping
  • Transport lock on front and rear: a latch locks the guides during transport
  • Groove depth 3 mm for secure PCB retention
  • ESD-safe, surface resistance according to DIN EN 61340-5-1
  • Stackable or suitable for turning operation
  • Supplied partly assembled, assembled version available under a separate part number

Applications

SMT production, reflow and wave soldering lines, storage and transport of assemblies between production steps.

Technical data

Manufacturercab
Model602.1
Manufacturer part number8917602
Series600
Side wall materialpolystyrene
PCB width10-250 mm
Max. PCB length387 mm
External dimensions W x D x H320 x 400 x 563 mm
Max. temperature of guides60 °C
Groove depth3 mm
Width adjustmentscrew clamping
ESD-safeyes
Max. ambient temperature50 °C
Weight (manufacturer)5.8 kg
Surface resistance< 10^9 ohms according to DIN EN 61340-5-1
Weight5.8 kg
Manufacturer Nr.8917602
HS-Code39239000
GPSR manufacturer informationcab Produkttechnik GmbH & Co. KG, Wilhelm-Schickard-Str. 14, DE-76131 Karlsruhe, www.cab.de
Condition of articleNew
Article authenticityOriginal product
ESD versionESD (antistatic)
