Diagonal cutter with comfort handles, narrow head, cutters 61 HRC, 140 mm - Knipex 70 02 140

Cutting wire to length in control cabinets and distribution boards rarely leaves much room. The 70 02 140 diagonal cutter answers that with a narrow head shape and precision cutting edges of approx. 61 HRC that cut medium hard wire up to 2.5 mm dia. and hard wire up to 1.8 mm dia. cleanly.

Benefits

• Narrow head style reaches into confined working areas without the edge tilting away from the wire.
• Precision cutting edges for soft and hard wire, additionally induction hardened to approx. 61 HRC for a long service life.
• Clean cut on thin copper wires right out to the tips of the cutting edges, with no frayed ends.
• Three-component comfort handles spread the hand pressure and allow many cuts one after another.
• Two KNIPEXtend interfaces on the handles accept extensions, for example for tool tethering.
• High quality material and precise workmanship to DIN ISO 5749, black atramentized with a polished head.

Areas of use

Electrical installation, control cabinet building, assembly and maintenance as well as general workshop tasks. The narrow head suits every job where little space is left between terminals and cable looms.

Standards and conformity

The cutter complies with DIN ISO 5749. According to the manufacturer it contains no substances of very high concern under REACH. The RoHS directive does not apply to this product.
