Filter mat F7-02 prefilter series 160/200, pack of 10 - ULT 02.0.578
A clogged prefilter cuts extraction volume and pushes the load onto the expensive main filter. The F7-02 filter mat is rated ISO ePM10 75% to ISO 16890 and traps solder fume particles ahead of the H13A combination filter cassette. Supplied as a pack of 10 for the LRA 160.1 MD.11 K and LRA 200.1 MD.20 K solder fume units.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The prefilter is the wear part of a solder fume extraction unit: it captures cooled sticky aerosols and particles while they are still in the intake path, before they reach the HEPA and adsorption stages. In the solder fume units of the ULT 160.1 and 200.1 series the F7-02 mat is the finer layer of the M5/F7 mat combination ahead of the H13A combination filter cassette. Supplied as a pack of 10 so scheduled changes never wait for a reorder.
Benefits
- Filter class F7, rated ISO ePM10 75% to ISO 16890
- Pack of 10 mats covers several change intervals
- Depth-loading medium binds a large share of the solder fume particles
- Short prefilter change intervals keep the H13 main filter working for a long time
- Storage filter for the exchange filter system of the ULT 160.1 and 200.1 series
Applications
Servicing of solder fume extraction at manual soldering benches, at robotic soldering cells and in repair and rework areas. The change interval depends on flux volume and operating hours, the usual trigger is the particulate filter loading indicator on the unit.
Compatibility and scope of delivery
For the solder fume units LRA 160.1 MD.11 K and LRA 200.1 MD.20 K, where the M5/F7 mat combination forms the prefilter stage. Scope of delivery: 10 F7-02 filter mats.
Technical data
| Item number | WL26479 |
|---|---|
| Model | 02.0.578 |
| Manufacturer | ULT |
| Manufacturer item number | 02.0.578 |
| Order unit | Pack |
| Content unit | 10 pieces |
| Filter type | Prefilter, storage filter |
| Filter class | F7, ISO ePM10 75% to ISO 16890 |
| Downstream main filter | Combination filter cassette H13A (4-00075) |
| Device series | LRA 160.1 MD.11 K, LRA 200.1 MD.20 K |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.0.578 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| VPE | 10 Stück |
| Norm | ISO 16890 |
| Filter class | F7 |
