Filter mat M5-02 prefilter for series 160/200 - ULT 02.0.572
M5 class prefilter mat for ULT extraction units of the ASD 160 and ASD 200 series. ULT rates the M5-02 mat ISO Coarse 85% to ISO 16890. It sits behind the Z-Line filter G4, holds back coarser particles and so extends the service life of the downstream main filter.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The M5-02 filter mat is the prefilter stage for ULT extraction units of the ASD 160 and ASD 200 series. In the ASD filter build-up it sits behind the Z-Line filter G4 and ahead of the particle filter cassette. It holds back coarser particles from the extracted air flow and so protects the more expensive main filter from premature loading.
Benefits
- Filter class M5, stated by ULT as ISO Coarse 85% to ISO 16890
- Depth-loading media, well suited to a broad particle spectrum and to cooled smoke fractions
- Extends the service life of the downstream main filter
- Prefilter with exact fit for ASD 160 and ASD 200
- Low-cost wear part with easy replacement
Applications
Prefiltration in dust and smoke extraction at workstations using ULT ASD 160/200 series units. ULT lists grinding, engraving, polishing, filling and dosing operations and restoration work for the ASD series. Changing the prefilter elements at shorter intervals keeps the main filter working for a long time.
Compatibility and scope of delivery
Suitable for ULT extraction units ASD 160 and ASD 200. Supplied as one piece.
Technical data
| Item number | WL26808 |
|---|---|
| Model | 02.0.572 |
| Manufacturer | ULT |
| Manufacturer item number | 02.0.572 |
| ULT designation | Filter mat M5-02 |
| Filter class | M5, ISO Coarse 85% to ISO 16890 |
| Filter type | Prefilter |
| Position | behind Z-Line filter G4, ahead of the particle filter cassette |
| Device series | ASD 160, ASD 200 |
| Order unit | Piece |
| Weight | 0.020000 |
| Manufacturer Nr. | 02.0.572 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | ISO 16890 |
| Filter class | M5 |
