Phillips bit PH1, 25 mm long, 1/4 inch drive, pack of 10 - Bahco 59S/PH1-10P
Phillips bit PH1 for the smaller sheet metal and enclosure screws used in equipment building. The 25 mm body keeps the load path short and the zinc-phosphated surface adds grip in the recess. Ten bits per box cover longer assembly runs.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
PH1 covers the screw sizes that turn up most often in equipment building. This bit keeps the load path short at 25 mm and comes in a pack of ten, so a worn bit is swapped in step with assembly instead of being pushed further.
Features
- Size PH1 for medium sheet metal, enclosure and equipment screws
- Overall length 25 mm, little torsion between holder and screw head
- 1/4 inch hex drive to DIN 3126-C 6.3 and ISO 1173
- High-performance steel alloy with a zinc-phosphated surface
- 10 bits per plastic box for longer assembly runs
Applications
Device and final assembly, control cabinet and enclosure building, maintenance and repair.
Compatibility and scope of delivery
Fits bit holders, ratcheting bit screwdrivers and cordless drivers with a 1/4 inch socket. The delivery comprises 10 bits in a plastic box.
Standards and notes
The drive conforms to DIN 3126-C 6.3 and ISO 1173. The bits are not VDE insulated and are therefore not approved for live working to IEC 60900. The manufacturer declares no dissipative version to IEC 61340-5-1 for these bits.
Technical data
| Property | Value |
|---|---|
| Brand | Bahco |
| Manufacturer part number | 59S/PH1-10P |
| Drive | 1/4 inch hex, DIN 3126-C 6.3, ISO 1173 |
| Finish | zinc-phosphated |
| Model | 59S/PH1 |
| Length | 25 mm |
| Sales unit | 1 sales unit |
| Content unit | 10 pieces |
| Battery included | no |
| VDE | no |
| Screw type | PH1 |
| Tool material | high-performance steel alloy |
| Packaging | set |
| Tool length | 25 mm |
| Weight | 0.1 kg |
| Manufacturer | Bahco |
| Manufacturer Nr. | 59S/PH1-10P |
| GPSR manufacturer information | BAHCO Werkzeuge, Maybachstr. 10, DE-71711 Steinheim, www.bahco-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
