Conical rework cartridge from the Metcal SMTC series with a 30° bent 0.76 mm tip and 16.51 mm length. The low 357 °C working temperature protects heat sensitive SMD parts. Made for rework on surface mounted components with MX series handpieces.
Rework cartridge conical 30° 0.76 x 16.51 mm 357 °C SMTC series - Metcal SMTC-0171
METCAL
Original product
Net price (excl. VAT)
€69.80
Item
WL28017
Manufacturer no.
SMTC-0171
ESD · IEC 61340-5-1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SMTC-0171
ConditionNew
Article
WL28017
Frequently Bought Together
-
This Item:
€69.80
-
Rework tip blade 0.5 x 5 mm 412 °C SMTC series - Metcal SMTC-164
€100.00
-
Rework tip slot for chip 0402/0603/0805 SMTC series - Metcal SMTC-088
€59.00
Total price
The bent rework cartridge SMTC-0171 runs at 357 °C, the gentle grade for temperature sensitive components and thin boards. The 16.51 mm long tip with 0.76 mm width reaches pads underneath neighbouring parts.
Benefits
- Working temperature 357 °C for heat sensitive components
- Fine 0.76 mm tip, bent 30°, 16.51 mm long
- Good access to pads in densely packed assemblies
- Tool-free cartridge change during operation
- For MX-H1-AVA and MX-RM3E handpieces of the MX series
Technical data
| Item number | WL28017 |
| Model | SMTC-0171 |
| Manufacturer | Metcal |
| Manufacturer item number | SMTC-0171 |
| Product series | SMTC series |
| Tip shape | conical |
| Tip alignment | bent 30° |
| Tip width | 0.76 mm |
| Tip length | 16.51 mm |
| Tip temperature | 357 °C |
| Suitable handpiece | MX-H1-AVA, MX-RM3E |
| Order unit | piece |
| Weight | 0.1 kg |
Applications
Rework on SMD parts, replacement of single chips and resistors as well as corrections on temperature sensitive assemblies and flexible boards.
Compatibility and scope of delivery
The cartridge works in the MX-H1-AVA and MX-RM3E handpieces of the Metcal MX series on the MX-500, MX-5000 and MX-5200 power units. Scope of delivery: 1 rework cartridge SMTC-0171.
SmartHeat control keeps the temperature constant without calibration, and the grounded tip suits ESD workplaces to IEC 61340-5-1.
| Certification | IEC 61340-5-1 |
|---|---|
| Manufacturer Nr. | SMTC-0171 |
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
