The product may differ from the illustration
The hoof shaped cavity holds a solder reservoir right at the joint, which prevents bridges when reworking SMD leads. At 2 x 11.6 mm this cartridge covers several pins in one pass. Designed for the MX-HPDC hand piece and for temperature sensitive rework.
Rework tip hoof-shaped 2 x 11.6 mm, SMTC series - Metcal SMTC-0185
METCAL Original product
Net price (excl. VAT)
€57.44
Item WL31322
Manufacturer no. SMTC-0185
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.SMTC-0185
ConditionNew
Article
WL31322
Frequently Bought Together
- This Item: €57.44
- Rework tip slot for chip 0402/0603/0805 SMTC series - Metcal SMTC-088 €59.00
- SMD soldering tip for QFP 48 on MX series, series 700 / 412 °C - Metcal SMTC-1115 €88.99
Total price
When reworking SMD lead rows the amount of solder held at the tip decides the result. The Metcal SMTC-0185 is a hoof shaped rework cartridge of the SMTC series measuring 2 x 11.6 mm for the MX-HPDC hand piece.
Benefits
- Hoof shape with a solder reservoir for clean lead rows without bridges
- Tip size of 2 x 11.6 mm covering several pins in one pass
- Made for rework on surface mounted components
- Suitable for temperature sensitive applications of the MX series
- Self regulating SmartHeat cartridge, changed without tools
Technical data
| Item no. | WL31322 |
| Model | SMTC-0185 |
| Manufacturer | Metcal |
| Manufacturer item no. | SMTC-0185 |
| Order unit | Piece |
| Product series | SMTC series |
| Tip shape | Hoof-shaped |
| Tip dimensions | 2 x 11.6 mm |
| Compatible hand piece | MX-HPDC |
| Weight | 0.1 kg |
Applications
Rework on SMD lead rows, drag soldering and solder distribution on fine pitch parts, correction of solder bridges as well as repair work on populated boards.
Compatibility and scope of delivery
The rework cartridge is designed for the MX-HPDC hand piece of the Metcal MX series. Delivery covers one single cartridge without hand piece and without power unit.
| Manufacturer Nr. | SMTC-0185 |
|---|---|
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
