Particulate filter H14 main filter series 200, 305 x 305 x 130 mm - ULT 02.0.517
HEPA filter of class H14 to DIN EN 1822 for the ULT extraction units LAS 200 and ASD 200. It forms the final particle stage of the NFM H14 filter system and holds back the finest airborne particles at a separation rate of 99.995 percent. The MDF filter shaft is a dimensionally exact fit and is changed without tools.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Soldering produces particles far below one micrometre that a prefilter can no longer hold. That job falls to the H14 particulate filter of the NFM H14 filter system, the last particle stage in the ULT units LAS 200 and ASD 200.
Benefits
- HEPA filter class H14 to DIN EN 1822, separation rate of 99.995 percent for the finest airborne particles
- Part of the matched NFM H14 filter system, so pressure drop inside the unit stays as designed
- MDF filter shaft with an exact 305 x 305 x 130 mm fit for a reliable seal without bypass
- Tool-free change, the saturated filter is removed as one piece
- Designed as a storage filter, no cleaning cycle and no cleaning equipment required
Applications
Scheduled filter replacement on LAS 200 solder fume extractors and ASD 200 extraction units in electronics manufacturing, rework and laboratory work. The change is due when the unit indicator responds or when volume flow at the capture point visibly drops.
Compatibility and scope of delivery
For the ULT series 200 only, specifically LAS 200 and ASD 200 with the NFM H14 filter system. One H14 particulate filter in its MDF shaft is supplied, prefilters are ordered separately.
The separation efficiency of class H14 is classified to DIN EN 1822, and ULT states a separation rate of 99.995 percent for the H14 particulate filter of the 200 series. Prefilter elements changed at regular intervals stop the main filter from clogging early and extend its service life.
Technical data
| Item number | WL35738 |
|---|---|
| Model | 02.0.517 |
| Manufacturer | ULT |
| Manufacturer item number | 02.0.517 |
| Filter type | main filter |
| Filter class | H14 |
| Separation rate | 99.995 percent |
| Filter system | NFM H14 |
| Dimensions L x W x H | 305 x 305 x 130 mm |
| Housing | MDF filter shaft |
| Standard | DIN EN 1822 |
| Order unit | piece |
| Device series | ASD 200, LAS 200 |
| Weight | 0.1 kg |
| Manufacturer Nr. | 02.0.517 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Länge [mm] | 305 |
| Norm | DIN EN 1822 |
