Desoldering tip D-inside 1.50 mm T series for DS-GUN-2 - Thermaltronics T75DT006
Heavy leads on power components hold a lot of solder and cool the tip quickly. The T75DT006 answers with a 1.50 mm inside diameter, a 13 mm tip length and a 350-398 °C working range. It is part of the T desoldering tip series for the DS-GUN-2 hand piece.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The larger the solder volume in a plated through hole, the wider the suction channel has to be so the melt is drawn off in one pass. The Thermaltronics T75DT006 has a 1.50 mm inside diameter and a 13 mm tip length, which suits the leads of power semiconductors, chokes and screw terminals.
Benefits
- 1.50 mm (0.06 in) inside diameter for joints with a high solder volume
- Working range of 350-398 °C, matched to lead-free alloys
- 13 mm tip length with direct heat coupling to the pad
- Tool-free change on the DS-GUN-2 hand piece
- RoHS compliant and suitable for lead-free processes
Applications
Desoldering power transistors, rectifiers, toroidal chokes and screw terminals on power supply and drive assemblies. It also helps on boards with thick copper layers where heat drains quickly into the plane.
Compatibility and scope of delivery
For the DS-GUN-2 desoldering hand piece on the TMT-5000S-1 and TMT-5000S-2 stations. One desoldering tip is supplied per order unit.
Technical data
| Item number | WL38366 |
|---|---|
| Model | T75DT006 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | T75DT006 |
| Product series | T desoldering tip series, 350-398 °C |
| Temperature range | 350-398 °C |
| Soldering or desoldering tip | Desoldering tip |
| Tip width (inside diameter) | 1.5 mm |
| Tip width in inches | 0.06 in |
| Tip length | 13 mm |
| Tip length in inches | 0.51 in |
| Suitable hand piece | DS-GUN-2 |
| Suitable stations | TMT-5000S-1, TMT-5000S-2 |
| Dimensions with packaging (LxWxH) | 175 mm x 19 mm x 19 mm |
| Dimensions with packaging in inches | 6.9 in x 0.7 in x 0.7 in |
| Order unit | Piece |
| Weight | 0.1 kg |
| Design | RoHS compliant, lead-free |
| Manufacturer Nr. | T75DT006 |
| HS-Code | 85159080 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Tip diameter/width [mm] | 1.5 |
| Series | T |
