Narrow chisel cartridge with a 1.0 mm edge and 9 mm tip length for joints down to roughly 1.27 mm pitch. It keeps the heat on its own pad instead of bridging into the neighbours and runs at a fixed 325-358 °C. For the TMT-5000S-1 and TMT-5000S-2 stations with the SHP-T hand piece.
Soldering tip chisel 1.0 mm 30 degree T series - Thermaltronics TM60CH178
THERMALTRONICS Original product
Net price (excl. VAT)
€13.25
Item WL38414
Manufacturer no. TM60CH178
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TM60CH178
ConditionNew
Article
WL38414
Frequently Bought Together
- This Item: €13.25
- Soldering tip bevelled 60° 1.00 mm T series for SHP-T - Thermaltronics T80BV010 €13.25
- Soldering tip sharp bent 30° 0.4 mm 350-398 °C T series - Thermaltronics TM70B325 €13.25
Total price
The closer the leads sit, the less edge width a tip may bring. With a 1.0 mm chisel face and 9 mm of reach, this T series cartridge lands on a single pad and still transfers enough energy for lead-free alloys.
Benefits
- 1.0 mm edge for fine pitch leads and small component pads
- 9 mm tip length keeps the joint in view while soldering
- Factory defined working range of 325-358 °C
- Lead-free capable and RoHS compliant
- Heater and sensor inside the cartridge, exchange without cooling the hand piece
Technical data
| Item number | WL38414 |
| Model | TM60CH178 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM60CH178 |
| Product series | T tip series, 325-358 °C |
| Temperature range | 325-358 °C |
| Soldering or desoldering tip | Soldering tip |
| Tip shape | Chisel |
| Tip width | 1 mm (0.04 in) |
| Tip length | 9 mm (0.35 in) |
| Suitable hand piece | SHP-T |
| Suitable stations | TMT-5000S-1, TMT-5000S-2 |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm (4.6 in x 1.3 in x 0.5 in) |
| Weight | 0.1 kg |
| Order unit | Piece |
| Compliance | RoHS compliant, lead-free |
Applications
Rework on fine pitch SMD parts, soldering individual resistors and capacitors, and corrections on connectors where a 1.5 mm edge would already touch two pads at once.
Compatibility and scope of delivery
Fits the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 stations. One soldering cartridge is included.
| Manufacturer Nr. | TM60CH178 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
