Hoof shaped tip, 3.3 mm wide with a 60 degree face, whose concave well holds a small solder reservoir and releases it evenly as the tip is drawn along. Rows of leads can be soldered in one pass instead of pin by pin. Tip length 17.9 mm, 325-358 °C.
Soldering tip hoof 60 degrees 3.3 mm T series - Thermaltronics TM60DS525
THERMALTRONICS
Original product
Net price (excl. VAT)
€24.29
Item
WL38428
Manufacturer no.
TM60DS525
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TM60DS525
ConditionNew
Article
WL38428
Frequently Bought Together
-
This Item:
€24.29
-
Soldering tip chisel 1.0 mm short 6.4 mm T series - Thermaltronics TM60CH179
€13.25
-
Solder tweezer tip pair blade 15.75 mm - Thermaltronics T70TZ160
€66.69
Total price
When soldering rows of leads, what matters is not tip width but how evenly solder is released. The hoof geometry of this T series cartridge, 3.3 mm across with a 60 degree face, picks up solder in its well and lays it down along the pin row as the tip is drawn.
Benefits
- Hoof shape with a concave solder well for drag soldering pin rows
- 3.3 mm tip width matched to common QFP and connector pitches
- 60 degree face for a flat, comfortable working angle
- 17.9 mm tip length to reach over tall neighbouring parts
- Curie point control at 325-358 °C, RoHS compliant
Technical data
| Item number | WL38428 |
| Model | TM60DS525 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM60DS525 |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm |
| Dimensions with packaging in inches (LxWxH) | 4.6 in x 1.3 in x 0.5 in |
| Order unit | Piece |
| Product series | T tip series, 325-358 °C |
| Temperature range | 325-358 °C |
| Soldering or desoldering tip | Soldering tip |
| Tip length | 17.9 mm |
| Tip length in inches | 0.7 in |
| Tip width | 3.3 mm |
| Tip width in inches | 0.13 in |
| Tip shape | hoof-shaped |
| Matching hand piece | SHP-T |
| Weight | 0.1 kg |
| Compliance | RoHS compliant, lead-free soldering |
Applications
Used for drag soldering QFP and SOIC packages, retouching connector headers and any task where several leads should be wetted in a single pass.
Compatibility and scope of delivery
For the SHP-T hand piece and the TMT-5000S-1 and TMT-5000S-2 stations. One soldering cartridge is supplied, order unit piece.
| Manufacturer Nr. | TM60DS525 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
