Needle fine conical tip with a 0.10 mm point for work under the microscope. The 13 mm micro fine T series cartridge delivers heat at 420-475 °C exactly where it is needed, without touching adjacent pads.
Soldering tip conical 0.10 mm, micro fine, T series - Thermaltronics TM80C001
THERMALTRONICS
Original product
Net price (excl. VAT)
€18.61
Item
WL38487
Manufacturer no.
TM80C001
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TM80C001
ConditionNew
Article
WL38487
Frequently Bought Together
-
This Item:
€18.61
-
Soldering tweezer tip pair micro fine 0.25 mm - Thermaltronics T60TZ003
€27.92
-
Solder tweezer tip pair blade 10.41 mm - Thermaltronics T70TZ100
€66.69
Total price
On 0201 parts, bond wire and broken track repairs the point radius decides whether the joint stays clean. At 0.10 mm the TM80C001 is one of the finest cartridges in the T series and is intended for microscope work.
Benefits
- 0.10 mm point diameter for 0201, bond wire and track repair
- Conical micro fine geometry with a 13 mm tip length
- Induction control holds 420-475 °C even with very little tip mass
- Cartridge change without tools and without recalibration
- Lead-free, RoHS compliant construction
Technical data
| Item number | WL38487 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM80C001 |
| Model | TM80C001 |
| Product series | T tip series, 420-475 °C |
| Temperature range | 420-475 °C |
| Type | Soldering tip |
| Tip shape | conical, micro fine |
| Tip alignment | straight |
| Tip length | 13 mm (0.51 in) |
| Tip width | 0.1 mm (0.004 in) |
| Compatible hand piece | SHP-T |
| Order unit | piece |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm (4.6 in x 1.3 in x 0.5 in) |
| Weight | 0.1 kg |
| Compliance | RoHS compliant, lead-free |
Applications
Rework under a stereo microscope, replacing 0201 parts, tacking thin wire to test points, repairing broken tracks.
Compatibility and scope of delivery
Fits the SHP-T hand piece and therefore the Thermaltronics TMT-5000S-1 and TMT-5000S-2 induction soldering stations. Delivery covers one cartridge, the heating element is built in and is replaced together with the tip.
The cartridge is RoHS compliant and lead-free, which makes it suitable for the usual SAC lead-free solder alloys.
| Manufacturer Nr. | TM80C001 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Series | T |
| Tip diameter/width [mm] | 0.100000 |
| Soldering tip shape | konisch |
