Suction slot 100 mm DN50 white - Alsident 1-5010-5

For soldering benches, dispensing stations and laboratory processes with a narrow, constant emission source, a suction slot captures far more per m³ of airflow than a broad hood. This 100 mm version fits extraction arms of the Alsident System 50 with a 50 mm tube diameter.

Benefits

• Suction gap for concentrated sources of contamination, high capture velocity right at the point of origin
• Internal distributor pipe for even extraction across the full 100 mm width
• Tube and suction gap in anodised aluminium with 10μ layer thickness
• Alternatively impact-resistant, chemically resistant polypropylene, also suitable for solvent vapour
• Direct DN50 connection without an adapter

Technical data

Applications

Typical positions are hand soldering and rework stations, bonding and dispensing benches, cleaning work with isopropanol and test or laboratory workplaces with a fixed source location.

Compatibility and scope of delivery

Fits Alsident System 50 extraction arms with a 50 mm tube diameter. One suction slot is supplied per order unit, without the extraction arm. For ESD protected areas the conductive black version is intended.
