Electric screwdriver 230 V lever start 3.8 - 7.0 Nm, 650 rpm, with pistol grip - Delvo DLV70A06L-ABK

If the run should be triggered deliberately, the lever takes over from pressure on the screw. This screwdriver delivers 3.8 to 7.0 Nm for machine screws from 5.0 to 8.0 mm.

Benefits

• Lever start, the tool can be placed and aligned before it runs, which helps on joints that are hard to reach.
• Direct connection to 230 V AC, no control unit or power supply is needed at the bench.
• Torque adjustable without steps from 3.8 - 7.0 Nm for machine screws from 5.0 - 8.0 mm. Torque is set steplessly on the adjustment ring, and the cover over it keeps the set value from being changed by accident.
• The detachable DLW2300 pistol grip is part of the delivery and puts the hand behind the driving axis, and it comes off in seconds for tight spots.
• Bit grounding is fitted as standard, so charge is led away through the tool instead of through the assembly. At ESD protected workstations nothing has to be retrofitted.
• Rated for cyclic work with 0.5 s on and 3.5 s off, which matches the rhythm of a manual assembly station. 3 m cord, 870 g with pistol grip at around 45 W, brushless motor with shut-off clutch and a design that conforms to the RoHS Directive.

Applications

Assembly of larger units in machine and device building, joints in sheet metal and castings as well as test and final assembly benches.

Matching accessories

Bits with a 4 mm shank are taken by the ADA-HR4-D63 adapter. The BAL-0515 and BAL-1020 tool balancers carry the tool weight, and the SGR-14 and SGR-23 screw grids keep the screws ready at the bench.
