Digital dispenser, programmable, for low viscosity fluids, 0 to 1 bar - Oki DX-355
Programmable time-pressure dispenser whose precision valve regulates pressure finely between 0 and 1 bar. Thin fluids can be dispensed drip-free as dots or beads, and ten profiles stay in memory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Thin fluids do not tolerate excess pressure. The DX-355 therefore works in the 0 to 1 bar range with a precision valve and a time resolution from 0.008 s. Infinitely adjustable vacuum suck-back stops a drop from running on between two cycles.
Benefits
- Fine 0 to 1 bar pressure range for low viscosity fluids
- Time range 0.008 to 60 s with +/- 0.001 % tolerance for repeatable dots and beads
- 10 storable dispensing profiles and 4 operating modes
- Digital display of time, pressure and vacuum
- I/O interface and RS-232 for PLC and robotic applications
- Small footprint of 152 x 165 mm and only 1.2 kg
Applications
Dot and line dispensing of low viscosity fluids in electronics production, precision engineering and laboratories, manually via foot switch or automated through the interface. For applications up to 6.9 bar, the sister model DX-350 is available.
Note
The TSD800-6 air filter is not included and must be installed with the dispenser to ensure proper air conditioning.
Technical data
| Input voltage | 100 to 240 VAC, 50/60 Hz |
|---|---|
| Operating pressure | 0 to 1 bar (0 to 15 psi), precision valve |
| Cycle rate | 1200 cycles/min |
| Time range | 0.008 to 60 s |
| Time tolerance | +/- 0.001 % |
| Vacuum suck-back | infinitely adjustable |
| Cycle modes | TIMED, PURGE, INTERRUPT, TEACH |
| Program memory | 10 dispensing profiles |
| Dot counter | yes |
| Interfaces | I/O, triggered by voltage or contact closure, RS-232 |
| Dimensions (L x W) | 152 x 165 mm |
| Weight | 1.2 kg |
| Colour | grey, black |
| Certification | CE, TÜV-GS, NRTL |
| ESD safe | no |
| Warranty | 1 year |
| Sales unit | 1 piece |
| Manufacturer | Oki |
| Manufacturer Nr. | DX-355 |
| HS-Code | 90282000 |
| GPSR manufacturer information | OK International Ltd, Eagle Close, Chandlers Ford, GB-SO53 4NF Hampshire, www.ok-international.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
Scope of delivery
- DX-355 dispenser
- Foot switch
- Power supply
- Sample tip kit
- 10 cc receiver head kit
- Holders
- Receiver head air hose holder
- Syringe barrel stand
