Chemisorption filter 305x305x250 mm for MDF filter shaft - ULT 02.1.509

Particle filters retain dust but no gases or vapours. This filter insert measuring 305x305x250 mm combines adsorption and chemisorption at a 50 to 50 volume ratio and adds an effective gas stage to the MDF filter shaft of a ULT system.

Benefits

• Built as an adsorption and chemisorption filter at 50/50 volume percent
• The chemisorptive fraction binds reactive gases that activated carbon alone holds only weakly
• 305x305x250 mm format fits the MDF filter shaft exactly
• Reduces odour exposure at the workplace in recirculation mode
• Slide-in insert, replaced during routine filter maintenance

Technical data

Applications

Gas and odour separation after the particle stage in the extraction of solder and laser fume and of bonding, coating and cleaning processes that release gaseous components alongside aerosols.

Compatibility and scope of delivery

Intended for ULT extraction and filter units with MDF filter shaft and installation size 305x305x250 mm. Supplied as one chemisorption filter 02.1.509 per piece.
