Dosiernadeln gerade Edelstahl 22G, 0,41 mm, 10 Stück - JBC ND22S6

Dosiernadeln gerade Edelstahl 22G, 0,41 mm, 10 Stück - JBC ND22S6

Skip to the beginning of the images gallery

The product may differ from the illustration

Straight stainless steel dispensing needles 22G with 0.41 mm inner diameter and 6 mm needle length for type 3 solder paste. Pack of 10.

Dosiernadeln gerade Edelstahl 22G, 0,41 mm, 10 Stück - JBC ND22S6

Name: Dosiernadeln gerade Edelstahl 22G, 0,41 mm, 10 Stück - JBC ND22S6
Brand: JBC
SKU: WL47728
Price: 6.37 EUR
Availability: InStock

JBC Original product

Net price (excl. VAT)

€6.37

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item WL47728

Manufacturer no. ND22S6

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.ND22S6

Country of originSpain

Customs tariff number85159080900

ConditionNew

Article

WL47728

Frequently Bought Together

This Item: Dosiernadeln gerade Edelstahl 22G, 0,41 mm, 10 Stück - JBC ND22S6
€6.37
Excl. 19% VAT , excl. Shipping Cost
Dispensing needle 25 G, conical blue, inner Ø 0.25 mm, 10 pcs - JBC ND25P
€8.49
Excl. 19% VAT , excl. Shipping Cost
Dosiernadeln gerade Edelstahl 25G, 0,25 mm, 10 Stück - JBC ND25S6
€6.37
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

The JBC ND22S6 straight stainless steel dispensing needles give an even, controlled solder paste deposit. With an inner diameter of 0.41 mm (gauge 22) they are matched to type 3 solder paste and medium pad geometries.

Benefits

Gauge 22 / 0.41 mm inner diameter for even paste flow with type 3 solder paste
Straight stainless steel cannula for dimensionally stable, repeatable dots
Short 6 mm needle length lowers pressure drop and clogging
24 mm overall length for good reach
Economical pack of 10

Technical data

Manufacturer	JBC
Model	ND22S6
Item number	WL47728
Manufacturer item number	ND22S6
Inner diameter	Gauge 22 / 0.41 mm
Needle length	6 mm
Overall length	24 mm
Tip shape	straight
Material	stainless steel
Recommended solder paste	type 3
ESD safe	no
Order unit	pack of 10

Applications

Metering of solder paste onto SMD pads
Application of flux and low viscosity adhesives
Repair and rework of assemblies

Compatibility and scope of supply

Fits JBC dispensing cartridges and common Luer lock dispenser systems. Scope of supply: 10 straight stainless steel dispensing needles 22G.

Origin: Spain. CE, RoHS.

Information

More Information
Manufacturer Nr.	ND22S6
Manufacturer	JBC
Country of Manufacture	Spain
Weight	0.100000
Colour	Stainless Steel
HS-Code	85159080900
GPSR manufacturer information	JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com
Article authenticity	Original product
Condition of article	New
