Bolt end cutting nippers high transmission ratio for hard wire Ø 3.5 mm, 64 HRC edges, 200 mm - Knipex 61 02 200

Knipex ✓ Original product Brand new

Bolt end cutting nippers with high lever transmission for soft wire from Ø 1 to 6 mm, medium hard wire up to Ø 4.0 mm, hard wire up to Ø 3.5 mm and piano wire up to Ø 3.0 mm. The transmission ratio lowers the hand force needed compared with conventional end cutters, and the cutting edges are additionally induction-hardened to approximately 64 HRC. 200 mm long at 435 g, tested to DIN ISO 5743.

Net
€50.09
excl. VAT
Item WL48264
Manufacturer no. 61 02 200
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Nipping hard wire right in front of the hand takes a lot of force with a conventional end cutter. The high transmission bolt end cutting nippers 61 02 200 handle hard wire up to Ø 3.5 mm and soft wire up to Ø 6 mm with markedly less effort, because the lever transmission carries the hand force through to the edges.

Benefits

  • Greater capacity with lower hand force than conventional bolt end cutting nippers, and better handling.
  • Cutting edges for soft wire up to Ø 6 mm, medium hard up to Ø 4.0 mm, hard up to Ø 3.5 mm and piano wire up to Ø 3.0 mm.
  • Cutting edges additionally induction-hardened to approximately 64 HRC, for a long service life even on hard material.
  • Slim multi-component grips without collar, so the tool is easier to guide and to carry.
  • Large contact surface on the handles spreads the pressure across the hand and makes work more comfortable.
  • Compact build at 200 mm length and 435 g, polished head and black atramentized body.

Areas of use

Fencing and wire work, reinforcing and tying wire, maintenance and assembly. Wherever wire has to be cut flush in front of the hand and a full size bolt cutter would be too bulky.

Standards and conformity

The tool is manufactured according to DIN ISO 5743. According to the manufacturer it contains no substances of very high concern under REACH, the RoHS directive does not apply.

Technical data

EAN4003773067047
Pliersblack atramentized
Headpolished
Handlesplastic coated
Weight435 g
Dimensions200 x 45 x 15 mm
StandardDIN ISO 5743
Cutting capacity soft wire (diameter)Ø 1 - 6 mm
Cutting capacity medium hard wire (diameter)Ø 4.0 mm
Cutting capacity hard wire (diameter)Ø 3.5 mm
Cutting capacity piano wire (diameter)Ø 3.0 mm
REACH conformitycontains no SVHC
RoHS conformitynot applicable
Weight0.435000
ManufacturerKnipex
Manufacturer Nr.61 02 200
GPSR manufacturer informationKNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de
Condition of articleNew
Article authenticityOriginal product
Height15 mm
Width45 mm
ColourBlack
Farbeschwarz
NormDIN ISO 5743
Overall length [mm]200.000000
