Automatic insulation stripper PreciStrip16, 0.08 to 16 mm², with cable cutter and length stop - Knipex 12 52 195

Terminating conductors of widely differing cross sections in a control cabinet normally means changing tools several times. The PreciStrip16 strips from 0.08 to 16 mm² with a single pair of pliers and adjusts the depth of cut automatically.

Benefits

• Wide capacity range from 0.08 to 16 mm², or AWG 28 to 6, from fine stranded to solid round cables without changing tools.
• Semi-circular grooved metal holding jaws provide a firm grip, parabolic stripping blades ensure an exact cut.
• The automatic mechanism regulates the cutting depth of the blades, its neutral point can be adjusted in fine steps for unusual insulating material or temperature.
• Cable cutter on top for copper and aluminium conductors, fine stranded up to 16 mm² and solid up to 6 mm².
• Adjustable length stop for repeatable stripping lengths, plus an inscription area for individualisation.
• Easily replaceable blade cassette and a tether attachment point for KNIPEX Tethered Tools accessories.

Technical data

Areas of use

Electrical installation, control cabinet building, controls and plant construction. Wherever many conductor cross sections are stripped in sequence and the stripping length has to stay reproducible.

Standards and conformity

According to the manufacturer the article contains substances of very high concern under REACH. The RoHS directive does not apply to this product. No tool standard is stated in the source.
