Precision insulation stripper with shaped blades for PTFE cable 0.25 to 6 mm², 195 mm - Knipex 12 12 06

PTFE insulation is tough and hard to cut cleanly with a standard tool. The 12 12 06 precision insulation stripper works with form-fitting blades matched to 0.25 / 0.75 / 1.5 / 2.5 / 4 / 6 mm² and severs the insulation all around without nicking the conductor.

Benefits

• Two high-quality pairs of blades cut the insulation evenly around the entire circumference, which gives a clean and uniform stripping result.
• The cable insulation stays free of pressure marks, so the function of the cable is retained.
• Replaceable shaped blades matched exactly to the respective conductor cross-section.
• Repeatable stripping lengths thanks to a length stop adjustable between 5 and 20 mm, made of glass fibre reinforced plastic and screw-fastened for a reliable and precise fit on the bolt.
• For PTFE insulated cable of 0.25 / 0.75 / 1.5 / 2.5 / 4 / 6 mm², six steps cover the usual range of cross-sections.
• Black oxide finished pliers with multi-component grips, 445 g at 195 mm length.

Technical data

Areas of use

Aerospace, measurement and control engineering, special machine building and anywhere PTFE insulated cables are assembled. The adjustable length stop pays off in the batch production of wiring harnesses.

Standards and conformity

The manufacturer does not state a tool standard for this product. According to the manufacturer the tool contains substances of very high concern under the REACH regulation, the corresponding entry is given in the technical data. The RoHS directive does not apply.
