Precision insulation stripper with shaped blades for PV cable 1.5 to 6 mm², AWG 16 to 10, 195 mm - Knipex 12 12 11

Solar cables carry multi-layer insulation that tends to tear or take pressure marks during stripping. The 12 12 11 precision insulation stripper is designed exactly for this and works with form-fitting blades for 1.5 / 2.5 / 4 / 6 mm², matching AWG 16 to 10.

Benefits

• Two high-quality pairs of blades cut the insulation evenly around the entire circumference, which gives a clean and uniform stripping result.
• The cable insulation stays free of pressure marks, so the function of the cable is retained.
• Replaceable shaped blades matched exactly to the respective conductor cross-section.
• Repeatable stripping lengths thanks to a length stop adjustable between 5 and 20 mm, made of glass fibre reinforced plastic and screw-fastened for a reliable and precise fit on the bolt.
• For PV cable of 1.5 / 2.5 / 4 / 6 mm², specifically designed for multi-layer insulation.
• The range of cross-sections corresponds to AWG 16 / 14 / 12 / 10, so cables in American sizing can be matched as well.
• Black oxide finished pliers with multi-component grips, 449 g at 195 mm length.

Technical data

Areas of use

Assembly of photovoltaic systems, preparation of solar cables and fitting of connectors on roof and open field sites. For the larger cross-sections 4 / 6 / 10 mm² the 12 12 12 version is intended.

Standards and conformity

The manufacturer does not state a tool standard for this product. According to the manufacturer the tool contains substances of very high concern under the REACH regulation, the corresponding entry is given in the technical data. The RoHS directive does not apply.
