Precision circlip pliers for external circlips on shafts with overexpansion guard, 130 mm - Knipex 49 41 A01

In series assembly the service life of the tips decides the cost per unit. On these precision circlip pliers the tips are inserted rather than turned, which gives them up to 10 times the service life. At 130 mm in length and 102 g in weight the tool stays light and controllable in the hand.

Benefits

• Inserted tips with up to 10 times longer service life than turned tips, designed for continuous use.
• Overexpansion guard with an end stop, adjustable using a hexagon socket screw, prevents rings from being stretched during series production.
• Precise, smoothly operating screw joint on a forged body guides the tips accurately.
• Large contact faces on the tips seat the ring without distortion, which makes fitting easier.
• Slim head style reaches shaft shoulders in confined installations, overall height only 11 mm.
• Internal opening spring is protected and captive, handles are coated with non-slip plastic.

Applications

Fitting and removing external circlips on shafts, above all in series production, jig and tool making, precision engineering and maintenance.

Standards and compliance

The pliers comply with DIN 5254 B. They contain no substances of very high concern as defined by the REACH regulation, and the RoHS directive does not apply to this hand tool.
