Knipex 95 61 190. wire rope cutter, forged, 190 mm

Name: Knipex 95 61 190. wire rope cutter, forged, 190 mm
Brand: Knipex
SKU: WL61927
Price: 39.68 EUR
Availability: InStock

€39.68

Excl. 19% VAT , excl. Shipping Cost

Article

WL61927

Manufacturer Nr.

95 61 190

Wire rope cutter, forged, 190 mm

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Knipex 95 61 190. wire rope cutter, forged, 190 mm
€39.68
Excl. 19% VAT , excl. Shipping Cost
Lindström HS 8132. Precision Diagonal Cutters ESD with oval head, XS, Ultra Flush
€78.64
Excl. 19% VAT , excl. Shipping Cost
Knipex 71 41 200 SB. CoBolt® Kompakt-Bolzenschneider mit Kunststoff überzogen, 20° abgewinkelt, schwarz atramentiert, 200 mm (SB-Karte/Blister)
€49.39
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

With two press profiles for end sleeves on Bowden sheaths and end caps for wire rope hoists. Comfortable working due to handy, slim design and internal opening spring. Bolted joint for precise blade guidance, adjustable. High transmission ratio for effort-saving work. Cutting edge hardness approx. 64 HRC. - Cutting value Cu-cable, stranded: 10mm² - Cutting value Cu-cable, stranded (diameter): Ø 7,0mm - Cutting value Cu-cable, fine stranded (diameter): Ø 6,0mm² - Cutting value wire (diameter): Ø 5,0mm - Cutting value medium hard wire (diameter): Ø 4,0mm - Cutting value piano wire (diameter): Ø 2,5mm - Cutting value iron (diameter): Ø 4mm - AWG: 7

With two press profiles for end sleeves on Bowden sheaths and end caps for wire ropes
Comfortable working due to handy, slim design and internal opening spring
Bolted joint for precise blade guidance, adjustable
High transmission ratio for effort-saving work
Cutting edge hardness approx. 64 HRC

Product details

item number	WL61927
model	95 61 190
manufacturer	KNIPEX
manufacturer item number	95 61 190
dimensions (LxWxH)	195 mm x 60 mm x 20 mm
dimensions with packaging (LxWxH)	229 mm x 119 mm x 52 mm
Packaging volume	1.417 dm³
order unit	piece
type of packaging	single pack
RoHS conform	no
VDE	no
ESD safe	no
tool length	190 mm
AWG	7
description head	polished
type of handle	covered with plastic
Cutting value copper cable, multistranded	10 mm²
Cutting value copper cable, multistranded (diameter)	7 mm
cutting value wire diameter medium	4 mm

Information

More Information
Manufacturer Nr.	95 61 190
Manufacturer	Knipex
Weight	0.100000
GPSR manufacturer information	KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de
Article authenticity	Original product
Condition of article	New
