Wire rope cutter forged with two crimping dies, wire rope up to 5 mm dia., 190 mm - Knipex 95 61 190

Anyone making up traction cables does more than cut, they also fit end ferrules and end caps. The forged 95 61 190 wire rope cutter combines both jobs. It cuts wire rope up to 5.0 mm dia. and carries two crimping dies, at 190 mm length and 310 g.

Benefits

• Two crimping dies for end caps on Bowden cable sheaths and end ferrules for traction cables, one tool instead of two.
• Cutting edge hardness of approx. 64 HRC, also suitable for medium hard wire up to 4.0 mm dia. and piano wire up to 2.5 mm dia.
• High leverage for reduced effort, even over many cuts in a row.
• Bolted joint for precise blade guidance, re-adjustable and therefore long lasting.
• Handy slim design with internal opening spring for comfortable work.
• Forged construction with polished head and plastic coated handles.

Technical data

Areas of use

Rope and lifting gear work, bicycle workshops, machine and plant construction, stage and event technology and maintenance. Wherever wire rope is cut to length and fitted with end ferrules or end caps.

Standards and conformity

According to the manufacturer the wire rope cutter contains no substances of very high concern under REACH. The RoHS directive does not apply to this product.
