Crimping pliers for RJ45 Western plugs 8-pin, with ratchet and stripping function, 190 mm - Knipex 97 51 13

Anyone assembling network outlets and patch cables needs the same crimp on all eight contacts, otherwise the link fails the measurement. Crimping pliers 97 51 13 press shielded and unshielded Western plugs RJ45 (8P8C) with a parallel movement and keep the quality repeatable through the ratchet, at 190 mm tool length and 345 g.

Benefits

• For data cables in telecommunication and networks, suitable for shielded and unshielded Western plugs RJ45 (8P8C).
• Adjustable retaining bracket, so all common RJ45 plugs with closed and non-closed housings fit into the seat.
• Separate crimping die for strain relief (cable clip), the cable jacket is secured in the same working step.
• High-quality blades for quick cutting and stripping of CAT cables, a second tool is not needed.
• Precise crimping process thanks to parallel crimping, the unlockable ratchet mechanism only releases after a full stroke and secures repetitive, high crimping quality.
• Force magnified by lever action for fatigue-free working, even when many plugs are terminated one after another.

Technical data

Areas of use

Network and telecommunication technology, patch cable assembly, installation and service on structured cabling. Because cutting, stripping and crimping happen in one tool, the pliers suit site work where little equipment is carried along.

Standards and conformity

The manufacturer does not state a tool standard for this product. According to the manufacturer the pliers contain no substances of very high concern under REACH. The RoHS directive is stated as not applicable.
