Desoldering tip THT inner Ø 2.4 mm outer Ø 4.8 mm for DT530 desoldering iron - JBC D530007
The D530007 desoldering tip of the D530 series picks up solder right at the component lead. An inner diameter of 2.4 mm surrounds pins up to 2.2 mm, so the suction air travels all around the pin and clears the plated through hole in one go. At 4.8 mm outside diameter the heat stays close to the pad.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When desoldering through hole parts, the fit of the tip decides the result. The D530007 wraps around leads up to 2.2 mm with an inner diameter of 2.4 mm, and the remaining annular gap guides the suction air around the pin to pull the molten solder out of the hole. The outer diameter of 4.8 mm keeps the heat where it is needed.
What the tip delivers in practice
- Inner diameter 2.4 mm for pins up to 2.2 mm, the suction channel stays clear and the air acts all around.
- Outer diameter 4.8 mm, heat input remains limited to the pad and the lead.
- A small gap between pin and tip with free air circulation shortens the contact time at the joint.
- D530 series with a straight bore, the cylinder can be cleared quickly after use.
- The matching handpiece is the DT530 desoldering iron, tips are swapped without changing the station setup.
Applications
Repair and rework on assembled boards, removal of pin headers, connectors and leaded components, service benches in electronics manufacturing and maintenance.
Compatibility and scope of delivery
The tip belongs to the D530 series and works on the DT530 desoldering iron. One piece in geometry S1 is supplied.
Technical data
| Length incl. packaging | 96 mm |
|---|---|
| Width incl. packaging | 45 mm |
| Height incl. packaging | 5 mm |
| Sales unit | 1 piece |
| Content unit | 1 piece |
| Battery included | no |
| Inner diameter (desoldering tip) | 2.4 mm |
| Tip type | Desoldering tip |
| Tip series | D530 |
| Pin diameter (max.) | 2.2 mm |
| Application | Desoldering THT components |
| Outer tip diameter | 4.8 mm |
| Tip geometry | S1 |
| Matching handpiece | DT530 |
| ESD safe | no |
| Weight | 0.01 kg |
| Manufacturer | JBC |
| Manufacturer Nr. | D530007 |
| HS-Code | 85159080 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
