ESD SMD cabinet 340/22, 3 drawers, 216 SMD Box 02 37 x 12 x 15 mm, black - Licefa 8900039

Elongated parts and short tape strips need more length than width. This SMD cabinet contains 216 SMD Box 02 hinged boxes with 37 x 12 x 15 mm internal size, 72 per drawer in 3 drawers, for sorted storage on a 352 x 265 mm footprint.

Benefits

• Boxes with 37 mm internal length take elongated parts and short tape strips without bending
• Boxes fitted in one block: 72 per drawer, each opened by its own hinged lid, the block can be lifted out
• Cabinet, drawers and boxes in dissipative PS at 10^4 to 10^11 ohm for protecting electrostatic sensitive devices to DIN EN 61340-5-1
• Fully assembled, drawers 340 x 250 x 22 mm inside
• Made in Germany

Applications

• Storing short tape strips and elongated components
• SMD assembly of small batches
• Picking component kits
• Laboratory and prototyping

Compatible with

• SMD drawer 340/22 with SMD Box 02 in one block or in a vacuum formed tray, to extend with the same box size
