MicroFine tweezer soldering tips, conical 0.4 x 6.2 mm, cartridge pair, 800 series - Metcal MFT-8CNB6204

Tiny chip components are heated and lifted in one move with soldering tweezers. The Metcal MFT-8CNB6204 is a pair of MicroFine tweezer tip cartridges, conical, 0.4 mm wide and 6.2 mm long, running at 468 °C as part of the 800 series. Also intended for ceramic components and joints with high heat demand under magnification.

Key benefits

• Tip size 0.4 x 6.2 mm, conical: fine access to the smallest SMD parts under the microscope
• 800 series with fixed temperature of 468 °C, set by the cartridge
• SmartHeat induction heating adjusts power in every soldering cycle and keeps the temperature constant
• Supplied as a pair, both tweezer arms are fitted at once

Applications

Temperature-critical soldering under the microscope: placing and removing small chip resistors and capacitors, repair and rework in electronics production. Also intended for ceramic components and joints with high heat demand under magnification.

Compatibility and scope of delivery

For the MicroFine tweezer handpieces MX-H10-MFT and CV-H10-MFT on Metcal MX and CV systems (MX-500, MX-5200, CV-500, CV-5200). Scope of delivery: 1 pair of MFT-8CNB6204 tip cartridges.
