Festo AEVC-100-10-A-P (188330) Short-Stroke Cylinder

Name: Festo AEVC-100-10-A-P (188330) Short-Stroke Cylinder
Brand: Festo
SKU: FES-188330
Price: 262.84 EUR
Availability: InStock

FESTO Original product

Net price (excl. VAT)

€262.84

Excl. 19% VAT , excl. Shipping Cost

In stock Fast shipping

Item FES-188330

Manufacturer no. AEVC-100-10-A-P

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.AEVC-100-10-A-P

EAN4052568149345

Customs tariff number84123100

ConditionNew

Article

FES-188330

Short-Stroke Cylinder

The product may differ from the illustration

Frequently Bought Together

This Item: Festo AEVC-100-10-A-P (188330) Short-Stroke Cylinder
€262.84
Excl. 19% VAT , excl. Shipping Cost
Festo ADVC-32-10-I-P-A (188205) Short-Stroke Cylinder
€85.62
Excl. 19% VAT , excl. Shipping Cost
Festo AEVC-80-10-A-P (188306) Short-Stroke Cylinder
€209.88
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	10,0
Piston diameter	100 mm
Spring return force for retracted piston rod [N]	140
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Principle of operation	Pressing single action
Construction set up	Piston piston rod
Position detection	without
Operating pressure [bar]	1 to 10
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	1 - low corrosion stress
ambient temperature [°C]	-20 to 80
Theoretical force at 6 bar, flow [N]	4.495,0
Moving mass [g]	678,00
Product weight [g]	2.850,0
Fastening type	With throughway bores With Accessories Selectively:
Pneumatic connection	G1/4
Material information	Copper and PTFE-free
Cover material	Aluminium wrought alloy anodized
Seals material	NBR TPE-U(PU)
Housing material	Aluminium wrought alloy anodized
Piston rod material	High-alloyed steel
Based on standard	ISO 6431 VDMA 24562 hole pattern

More Information
Manufacturer Nr.	AEVC-100-10-A-P
Manufacturer	Festo
EAN	4052568149345
Weight	2.100000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
