Festo DSM-10-90-P-FW (185940) Semi-Rotary Drive

Name: Festo DSM-10-90-P-FW (185940) Semi-Rotary Drive
Brand: Festo
SKU: FES-185940
Price: 2229 EUR
Availability: InStock

€2,229.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-185940

Manufacturer Nr.

DSM-10-90-P-FW

Semi-Rotary Drive

The product may differ from the illustration

Frequently Bought Together

This Item: Festo DSM-10-90-P-FW (185940) Semi-Rotary Drive
€2,229.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSL-16-25-270-P-A-S2-B (556390) Swivel/Linear Unit
€80,298.00
Excl. 19% VAT , excl. Shipping Cost
Festo DSM-6-90-P-A (173195) Semi-Rotary Drive
€22,961.00
Excl. 19% VAT , excl. Shipping Cost

Total price

size	10
Dampening angle [deg]	0,5
Swivel angle [deg]	0 to 90
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Principle of operation	double acting
Construction set up	Rotary vane
Position detection	without
Operating pressure [bar]	2.5 to 8
Max. swivel frequency at 6 bar [Hz]	3,0
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
ambient temperature [°C]	0 to 60
Theoretical torque at 6 bar [Nm]	0,85
Permitted mass moment of inertia [kg/m²]	0,00260
Product weight [g]	150
Fastening type	with female thread
Pneumatic connection	M3
Material information	Copper and PTFE-free RoHs compliant
Drive shaft material	High-alloyed stainless steels
Seals material	TPE-U(PU)
Housing material	aluminium anodized
Information about operating and control medium	Oiled operation possible (required in further operations)

More Information
Manufacturer Nr.	DSM-10-90-P-FW
Manufacturer	Festo
EAN	4052568146290
Weight	0.200000
HS-Code	84123900
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
