Festo valve for fast, reliable control of compressed-air direction and flow.
Foot Valve With Detent FP-5-1/4-B - Festo 8997
FESTO
Original product
Net price (excl. VAT)
€430.93
Item
FES-8997
Manufacturer no.
FP-5-1/4-B
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.FP-5-1/4-B
EAN4052568111366
Customs tariff number84812090
ConditionNew
Article
FES-8997
Frequently Bought Together
-
This Item:
€430.93
-
Pushbutton Valve VHEF-PTCZ-B32-G14 - Festo 5299714
€104.85
-
Finger Lever Valve THO-3-1/4-B - Festo 8990
€151.28
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 bistable |
| Actuation type | Manually |
| Normal nominal flow [l/min] | 550 |
| Operating pressure [bar] | -0.95 to 10 |
| Construction set up | Plate seat |
| Reset mode | Mechanical spring |
| Nominal width [mm] | 7 |
| installation position | arbitrary |
| Control type | Direct |
| Flow direction | Not reversible |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| ambient temperature [°C] | -10 to 60 |
| actuating force [N] | 82,0 |
| Product weight [g] | 1.845 |
| Fastening type | With throughway bores |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Pneumatic connection 4 | G1/4 |
| Pneumatic connection 5 | G1/4 |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | FP-5-1/4-B |
| Manufacturer | Festo |
| EAN | 4052568111366 |
| Weight | 1.800000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/4 |
| Nennweite DN [mm] | 7 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | 5/2 bistable |
| Durchfluss [l/min] | 550 |
| Mounting position | arbitrary |
| Design | Plate seat |
| Position sensing | No |
| Actuation type | Manually |
