Manual Override HAB-1/2 - Festo 184588
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
Technical data
| installation position | arbitrary |
|---|---|
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Fastening type | Screwable |
| Housing material | Aluminium wrought alloy<br>anodized |
| Material information | RoHs compliant |
| Nominal width [mm] | 14,0 |
| Valve function | Venting element |
| Operating pressure [bar] | 0 to 10 |
| Normal nominal flow venting [l/min] | 165 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Medium temperature [°C] | -20 to 80 |
| Pneumatic connection 1 | G1/2 |
| Pneumatic connection 2 | G1/2 |
| Weight | 0.035000 |
| Manufacturer | Festo |
| Manufacturer Nr. | HAB-1/2 |
| EAN | 4052568014506 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Aluminium |
| Nennweite DN [mm] | 14 |
| Medium | Compressed air |
| Funktion | Exhaust element |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Operating conditions | ISO 8573-1 |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/2 |
| Temperature (max.) | 80 |
