Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
Manual Override HAB-1/4 - Festo 184586
FESTO
Original product
Net price (excl. VAT)
€21.27
Item
FES-184586
Manufacturer no.
HAB-1/4
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.HAB-1/4
EAN4052568014490
Customs tariff number84812090
ConditionNew
Article
FES-184586
Frequently Bought Together
-
This Item:
€21.27
-
Amplifier Actuator LSK-6000 - Festo 3716
€293.73
-
Hand Lever VAOH-F7-11-H9-A-22 - Festo 4895384
€15.67
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| installation position | arbitrary |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Fastening type | Screwable |
| Housing material | Aluminium wrought alloy<br>anodized |
| Material information | RoHs compliant |
| Nominal width [mm] | 7,0 |
| Valve function | Venting element |
| Operating pressure [bar] | 0 to 10 |
| Normal nominal flow venting [l/min] | 165 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Medium temperature [°C] | -20 to 80 |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Weight | 0.016000 |
|---|---|
| Manufacturer | Festo |
| Manufacturer Nr. | HAB-1/4 |
| EAN | 4052568014490 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Aluminium |
| Nennweite DN [mm] | 7 |
| Medium | Compressed air |
| Funktion | Exhaust element |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Operating conditions | ISO 8573-1 |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/4 |
| Temperature (max.) | 80 |
