Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Connecting Cable KMP6-26P-16-2,5 - Festo 527546
FESTO Original product
Net price (excl. VAT)
€95.30
Item FES-527546
Manufacturer no. KMP6-26P-16-2,5
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.KMP6-26P-16-2,5
EAN4052568162719
Customs tariff number85444290
ConditionNew
Article
FES-527546
Frequently Bought Together
- This Item: €95.30
- Connecting Cable NEBV-S1G44-K-2.5-N-LE39 - Festo 565289 €89.18
- Connecting Cable NEBV-S1WA44-K-10-N-LE44-S9 - Festo 575422 €198.72
Total price
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
| Product weight [g] | 280 |
| Operating voltage range DC [V] | 0 to 30 |
| Cable length [MTR] | 2,5 |
| Cable diameter [mm] | 8,80 |
| Cable set up | 20x0,25 |
| Protection category | IP40 |
| ambient temperature [°C] | -25 to 70 |
| Cable sleeve material | PVC |
| Housing material | PBT reinforced |
| Plug contacts material | Copper alloy gold plated |
| Line designation | Without sign holder |
| Connection frequency | 50 |
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | Angular |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | straight |
| Electrical connection 1, connection technology | Sub-D |
| Electrical connection 1, number of pins / wires | 26 |
| Electrical connection 1, occupied pin / wire | 20 |
| Electrical connection 1, fastening type | 2x screw 4-40 UNC |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, connection type | cable |
| Electrical connection 2, connection technology | Open end |
| Electrical connection 2, number of pins / wires | 20 |
| Electrical connection 2, occupied pin / wire | 20 |
| Nominal operating voltage DC [V] | 24 |
| Current carrying capacity at 40°C [A] | 2,8 |
| Surge voltage strength [kV] | 1 |
| Line properties | Standard |
| Test conditions line | Test conditions on request |
| Bending radius, permanent cable placement [mm] | >= 88 mm |
| Bending radius, moving cable placement [mm] | >= 132 mm |
| Tolerance cable diameter | ± 0,25 mm |
| Conductor - nominal cross-section [mm²] | 0,25 |
| Wire ends | Cut dull |
| Information about protection category | In mounted condition |
| Ambient temperature for moving cable placements [°C] | -5 to 70 |
| Bearing temperature [°C] | -25 to 75 |
| CE certificate (see declaration of conformity) | nach EU-RoHS-RL |
| Material information | RoHs compliant |
| Degree of contamination | 2 |
| Cable shield colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Housing colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Complies to standard | DIN 41652 |
| Screw lock material | brass, nickel-plated |
| Norm | DIN 41652 |
|---|---|
| Manufacturer Nr. | KMP6-26P-16-2,5 |
| Manufacturer | Festo |
| EAN | 4052568162719 |
| Weight | 0.330000 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 70 |
| Werkstoff | PBT |
| Schutzart | IP40 |
| Serie | KMP6 |
| Betriebsspannung | 24 V DC |
| Position sensing | No |
