Genuine Festo accessory for exact mounting, fastening and extension of the associated component.
Intermediate Plate MUH-ZP-D-3-L-24G - Festo 151715
FESTO Original product
Net price (excl. VAT)
€350.81
Item FES-151715
Manufacturer no. MUH-ZP-D-3-L-24G
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.MUH-ZP-D-3-L-24G
EAN4052568117146
Customs tariff number84819000
ConditionNew
Article
FES-151715
Frequently Bought Together
- This Item: €350.81
- Sub-Base VABS-S2-1S-G38-B-K1 - Festo 546102 €55.48
- Manifold Sub-Base NAV-1/4-1C-ISO - Festo 10173 €25.20
Total price
Genuine Festo accessory for exact mounting, fastening and extension of the associated component. The key technical data of this genuine Festo article are listed below.
| Product weight [g] | 500 |
| Material information | RoHs compliant |
| Permission | c UL us - Recognized (OL) |
| Fastening type | With throughway bores |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Operating pressure [bar] | -0.9 to 10 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -5 to 50 |
| ambient temperature [°C] | -5 to 50 |
| Nominal width [mm] | 14,5 |
| Pitch dimension [mm] | 72 |
| Actuation type | Electrical |
| installation position | arbitrary |
| Hand assist actuation | tentative |
| Reset mode | Mechanical spring |
| Control type | Direct |
| Flow direction | Not reversible |
| Control pressure [bar] | 2 to 10 |
| Nominal operating voltage DC [V] | 24 |
| Permitted voltage oscillations | ± 10 % |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Bearing temperature [°C] | -20 to 40 |
| Protection category | IP65 |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Seals material | NBR |
| Manufacturer Nr. | MUH-ZP-D-3-L-24G |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568117146 |
| Weight | 0.500000 |
| HS-Code | 84819000 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Betriebsdruck max [bar] | 10.000000 |
| Schutzart | IP65 |
| Betriebsspannung | 24 V DC |
| Nennweite DN [mm] | 14,5 |
| Dichtmaterial | NBR |
| Medium | Druckluft |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Position sensing | No |
| Actuation type | Electrical |
