Connecting Cable NEBV-C-S1WA25HS-K-5-N-LE25-S10 - Festo 2265132
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Net
excl. VAT
€115.82
Item
FES-2265132
Manufacturer no.
NEBV-C-S1WA25HS-K-5-N-LE25-S10
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
Technical data
| Based on standard | DIN 47100 |
|---|---|
| Line designation | Without sign holder |
| Connection frequency | 50 |
| Product weight [g] | 860 |
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | Angular |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | Angled |
| Electrical connection 1, connection technology | Sub-D |
| Electrical connection 1, number of pins / wires | 25 |
| Electrical connection 1, occupied pin / wire | 25 |
| Electrical connection 1, fastening type | 2x screw 4-40 UNC<br>With seal |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, connection type | cable |
| Electrical connection 2, connection technology | Open end |
| Electrical connection 2, number of pins / wires | 25 |
| Operating voltage range DC [V] | 0 to 30 |
| Current carrying capacity at 40°C [A] | 2,60 |
| Protection line connection | Not available |
| Cable length [MTR] | 5,0 |
| Line properties | Standard |
| Bending radius, permanent cable placement [mm] | >= 41 mm |
| Bending radius, moving cable placement [mm] | >= 122 mm |
| Cable diameter [mm] | 10,2 |
| Tolerance cable diameter | ± 0,25 mm |
| Cable set up | 25x0,34 |
| Conductor - nominal cross-section [mm²] | 0,34 |
| Protection category | IP65<br>IP67<br>IP69K |
| Information about protection category | In mounted condition |
| Special features | Easy to clean |
| ambient temperature [°C] | -5 to 60 |
| Ambient temperature for moving cable placements [°C] | -5 to 60 |
| Bearing temperature [°C] | -20 to 40 |
| Material information | RoHs compliant |
| Degree of contamination | 3 |
| Corrosion resistant class KBK | 3 - severe corrosion stress |
| Cable sleeve material | PVC |
| Cable shield colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Housing material | PA reinforced |
| Housing colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Screws material | Stainless steel |
| Seals material | EPDM |
| Plug contacts material | Bronze gold plated |
| Insulation sleeve material | PVC |
| Weight | 0.9 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | NEBV-C-S1WA25HS-K-5-N-LE25-S10 |
| EAN | 4052568253141 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Polyamide (PA) |
| Dichtmaterial | EPDM |
| Corrosion resistance class CRC | 3 - severe corrosion stress |
| Norm | DIN 47100 |
| Series | NEBV |
| Protection class (IP) | IP65 |
| Temperature (max.) | 60 |
