Connecting Cable NEBV-S1W37-K-10-LE37 - Festo 539248
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Net
excl. VAT
€247.67
Item
FES-539248
Manufacturer no.
NEBV-S1W37-K-10-LE37
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
Technical data
| Line designation | With Sign carrier |
|---|---|
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | Angular |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | Angled |
| Electrical connection 1, connection technology | Sub-D |
| Electrical connection 1, number of pins / wires | 37 |
| Electrical connection 1, occupied pin / wire | 37 |
| Electrical connection 1, fastening type | 3x M4 screws |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, connection type | cable |
| Electrical connection 2, connection technology | Open end |
| Electrical connection 2, number of pins / wires | 37 |
| Operating voltage range DC [V] | 0 to 30 |
| Current carrying capacity at 40°C [A] | 2,00 |
| Cable length [MTR] | 10,0 |
| Line properties | Standard |
| Bending radius, permanent cable placement [mm] | >= 51 mm |
| Bending radius, moving cable placement [mm] | >= 128 mm |
| Cable diameter [mm] | 12,8 |
| Cable set up | 37x0,34 |
| Conductor - nominal cross-section [mm²] | 0,34 |
| Protection category | IP65<br>NEMA 4 |
| Information about protection category | In mounted condition |
| ambient temperature [°C] | -5 to 50 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Cable sleeve material | TPE-U(PUR) |
| Cable shield colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Housing material | PA |
| Insulation sleeve material | PVC |
| Field of application | Only for multi-pin connection distributor VTSA/VTSA-F |
| Complies to standard | DIN 47100 |
| Electrical connection 2, occupied pin / wire | 37 |
| Surge voltage strength [kV] | 1,0 |
| Test conditions line | Test conditions on request |
| Weight | 2.6 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | NEBV-S1W37-K-10-LE37 |
| EAN | 4052568177331 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Polyamide (PA) |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Norm | DIN 47100 |
| Series | NEBV |
| Protection class (IP) | IP65 |
| Temperature (max.) | 50 |
