Festo valve for fast, reliable control of compressed-air direction and flow.
Hand Lever Valve VHEF-HS-B52-G14 - Festo 4165864
FESTO Original product
Net price (excl. VAT)
€197.93
Item FES-4165864
Manufacturer no. VHEF-HS-B52-G14
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VHEF-HS-B52-G14
EAN4052568291495
Customs tariff number84812090
ConditionNew
Article
FES-4165864
Frequently Bought Together
- This Item: €197.93
- Finger Lever Valve VHEF-L-M52-E-G14 - Festo 4500004 €128.04
- Hand Lever Valve VHER-H-B43U-B-G14 - Festo 3515286 €125.56
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 bistable |
| Actuation type | Manually |
| Build.width [mm] | 20 |
| Normal nominal flow [l/min] | 1.200 |
| Betriebsdruck Mpa [MPa] | -0,095 bis 1 |
| Operating pressure [bar] | -0.95 to 10 |
| Construction set up | Piston pusher |
| Nominal width [mm] | 7,0 |
| Exhaust function | Can be throttled |
| User information | Only actuate by hand |
| Sealing principle | Soft |
| installation position | arbitrary |
| Control type | Direct |
| Flow direction | Reversible |
| Überdeckung | positive Überdeckung |
| Max. switching frequency [Hz] | 0,5 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| Actuation torque [Nm] | 0,6 |
| Max. force on actuation [N] | 200 |
| Max. cross-force on actuation [N] | 200 |
| Product weight [g] | 298 |
| Fastening type | Front panel integration<br>With throughway bores<br>Selectively: |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Material information | RoHs compliant |
| Cover material | PA reinforced |
| Seals material | NBR |
| Housing material | Aluminium wrought alloy, anodised |
| Lever material | PA reinforced |
| Pneumatic connection 4 | G1/4 |
| Pneumatic connection 5 | G1/4 |
| Hand assist actuation | Ratcheting |
| Manufacturer Nr. | VHEF-HS-B52-G14 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568291495 |
| Weight | 0.310000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Werkstoff | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatischer Anschluss | G1/4 |
| Serie | VHEF |
| Nennweite DN [mm] | 7 |
| Dichtmaterial | NBR |
| Medium | Druckluft |
| Funktion | 5/2 bistabil |
| Durchfluss [l/min] | 1200 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Design | Piston pusher |
| Position sensing | No |
| Actuation type | Manually |
