Festo VHER-H-B43C-B-G12 (3192066) Hand Lever Valve
€18,149.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-3192066
Manufacturer Nr.
VHER-H-B43C-B-G12
Hand Lever Valve
Frequently Bought Together
-
This Item:
€18,149.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VHEF-ES-B53E-G18 (4106820) Selector Valve
€10,116.00Excl. 19% VAT , excl. Shipping Cost
-
Festo FP-5-1/4-B (8997) Foot Valve With Detent
€41,219.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 4/3 closed |
| Actuation type | Manually |
| Build.width [mm] | 80 |
| Normal nominal flow [l/min] | 3.800 |
| Operating pressure [bar] | 0 to 10 |
| Information about operating pressure | Vacuum mode -0.95 to 0 bar, may only be connected to connection 3 For two-pressure mode, the pressure on connection 1 must be higher than on connection 3. |
| Construction set up | Rotary disc |
| Nominal width [mm] | 12 |
| Exhaust function | Can be throttled |
| User information | Only actuate by hand |
| Sealing principle | Hard |
| Control type | Direct |
| Flow direction | Not reversible |
| Freedom from cross-talk | yes |
| Switching position display | With Accessories |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -20 to 80 |
| ambient temperature [°C] | -20 to 80 |
| Actuation torque [Nm] | 5,0 |
| Product weight [g] | 860 |
| Fastening type | Front panel integration With throughway bores Selectively: |
| Pneumatic connection 1 | G1/2 |
| Pneumatic connection 2 | G1/2 |
| Pneumatic connection 3 | G1/2 |
| Pneumatic connection 4 | G1/2 |
| Material information | Copper and PTFE-free RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Lever material | Aluminium die casting |
| Manufacturer Nr. | VHER-H-B43C-B-G12 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568268817 |
| Weight | 0.900000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
