Festo valve for fast, reliable control of compressed-air direction and flow.
Stem Actuated Valve VS-4-1/8 - Festo 3394
FESTO
Original product
Net price (excl. VAT)
€237.42
Item
FES-3394
Manufacturer no.
VS-4-1/8
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS-4-1/8
EAN4052568008338
Customs tariff number84812090
ConditionNew
Article
FES-3394
Frequently Bought Together
-
This Item:
€237.42
-
Pushbutton Valve VHEF-PTCZ-M32-M-G18 - Festo 5299706
€83.88
-
Roller Lever Valve L-5-1/4-B - Festo 8993
€243.79
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 4/2 monostable |
| Actuation type | Mechanical |
| Normal nominal flow [l/min] | 140 to 147 |
| Operating pressure [bar] | 3.5 to 8 |
| Construction set up | Plate seat |
| Reset mode | Mechanical spring |
| Sealing principle | Soft |
| installation position | arbitrary |
| Control type | pilot operated |
| Flow direction | Not reversible |
| Information about force dynamic sampling | Switching frequency at least 1/year |
| Operating medium | Compressed air to ISO8573-1:2010 [-:-:-] |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| actuating force [N] | 3,20 |
| Fastening type | With throughway bores |
| Pneumatic connection 1 | G1/8 |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 3 | G1/8 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Housing material | aluminium<br>anodized |
| Pneumatic connection 4 | G1/8 |
| Nominal width [mm] | 3,5 |
| Exhaust function | Can be throttled |
| Control air supply | Internal |
| control medium | Compressed air to ISO8573-1:2010 [-:-:-] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Product weight [g] | 220 |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | VS-4-1/8 |
| Manufacturer | Festo |
| EAN | 4052568008338 |
| Weight | 0.175000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatic connection | G1/8 |
| Nennweite DN [mm] | 3,5 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | 4/2 monostable |
| Durchfluss [l/min] | 140147 |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Design | Plate seat |
| Position sensing | No |
| Actuation type | Mechanical |
