Electronics end cutting nippers ESD, soft wire up to 1.4 mm dia., cutters 56 HRC, 115 mm - Knipex 64 12 115 ESD

When reworking populated boards the leads have to be cut flush and close to the board without static discharging through the tool. The 64 12 115 ESD electronics end cutting nippers have electrically dissipative handles and laser hardened edges of at least 56 HRC that cut soft wire up to 1.4 mm dia.

Benefits

• Precision pliers for the finest cutting work, for example in electronics and precision mechanics.
• Electrically dissipative handles with two-colour multi-component sleeves in black and grey.
• Box type precision joint and low-friction double spring for smooth and even opening.
• Cutting edges additionally laser hardened, hardness at least 56 HRC. Medium hard wire is cut up to 0.8 mm dia.
• Head only 11 mm wide, the cutting edge length of 16 mm runs across the whole jaw.
• The mirror polish with a fine oil film protects against rust. No chrome flakes come loose that could cause circuit faults.

Technical data

Areas of use

Assembly, rework and repair of electronic modules at ESD workstations, plus precision mechanics, laboratory work and prototyping. End cutting nippers shorten leads straight from the front, where a diagonal cutter cannot reach between the components.

Standards and conformity

The tool complies with DIN ISO 9654 and DIN EN 61 340-5 for ESD protected areas. According to the manufacturer the tool contains no substances of very high concern under REACH. The RoHS directive does not apply to this product.
