ESD automatic soldering iron 150 W with automatic solder feed and two trigger buttons - JBC ALE250
The ALE250 is an ESD automatic soldering iron with 150 W maximum power and automatic solder feed. Two trigger buttons run on separate settings and use the C250, C250E and C245L cartridge ranges. It works exclusively with the ALE automatic soldering station.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The JBC ALE250 is the new version of the automatic soldering iron for automatic solder feed, aimed at repetitive soldering tasks where one hand needs to stay free. Dynamic tool setting allows different solder joints to be reached, even in hard-to-access positions.
Benefits
- Maximum power of 150 W for fast thermal recovery
- Two trigger buttons, each with its own setting, for repetitive tasks
- Uses the C250, C250E and C245L cartridge ranges
- Rotation system aligns the cartridge exactly with the guide for higher precision
- ESD-safe for use at antistatic workstations
Applications
Repetitive soldering in production and rework, especially at hard-to-reach joints where a free hand is needed, for example when working with tweezers.
Compatibility and scope of delivery
The ALE250 works exclusively with the ALE automatic soldering station. The wire guide is not included and is chosen separately as a guide kit to match the solder wire diameter (see wire guide kits and curved guide nozzle 0032589).
ESD-safe. Manufactured by JBC, Spain.
Technical data
| Article number | ALE250-B |
|---|---|
| Type | Automatic soldering iron with solder feed |
| Maximum power | 150 W |
| Cartridge ranges | C250, C250E, C245L |
| Length | 130 mm |
| Width | 14 mm |
| Height | 30 mm |
| ESD-safe | yes |
| Weight | 0.1 kg |
| Manufacturer | JBC |
| Manufacturer Nr. | ALE250-B |
| HS-Code | 85159080900 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
| ESD version | ESD (antistatic) |
| Power (W) | 150 W |
| Temperature range | 90-450 °C |
| Temperature (max.) | up to 450 °C |
