Calibrated teraohmmeter kit with barcode and QR reader
Calibrated complete kit of the Safe-Stat RM 4000 teraohmmeter with barcode and QR reader, test leads, electrodes, temperature and humidity sensor, SD card and mains adapter. Measures 5 kΩ to 2 TΩ at 10 V and 100 V per IEC 61340 and documents every check in an audit-proof way.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The calibrated complete kit supplies the Safe-Stat RM 4000 teraohmmeter with full accessories for standard-compliant resistance measurement in the EPA. Its integrated barcode and QR reader uniquely identifies every test object so that recurring checks are stored and archived in an audit-proof way.
Key benefits
- Delivered calibrated: meter with calibration certificate, ready for audits.
- Unambiguous object assignment: integrated barcode and QR reader links each reading to the correct test object.
- Standard-compliant measurement: surface, point-to-point and resistance-to-ground at 10 V and 100 V per IEC 61340.
- Wide range: 5 kΩ to 2 TΩ with freely configurable limit values.
- Automatic documentation: memory for over 5,000 records including temperature, humidity, date and time.
Applications
- Recurring testing of ESD workstations and floor coverings in the EPA
- Internal and external ESD audits with audit-proof records
- Measurement of surface, point-to-point and resistance-to-ground values
Standards and compliance
Captures surface, point-to-point and resistance-to-ground values in line with the IEC 61340-5-1 standard series.
Technical data
| Test voltage | 10 V and 100 V |
|---|---|
| Measuring range | 5 x 103 to 2 x 1012 Ω |
| Accuracy | +/-5 % |
| Memory | over 5,000 readings on SD card |
| Power | lithium-ion battery or mains adapter |
| Meter weight incl. battery | approx. 400 g |
| Meter dimensions | approx. 210 x 105 x 40 mm |
| Weight | 8 kg |
| Manufacturer | A1-ESD |
| Manufacturer Nr. | C-212-4000-SDQR-KIT |
| HS-Code | 90303900 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Sales unit | 1 Set |
| ESD version | ESD (antistatic) |
| ESD equipment | ESD-Messgeräte |
| Certification | IEC 61340, IEC 61340-5-1 |
Scope of delivery
- Safe-Stat RM 4000 meter, calibrated
- Shielded test leads and electrodes
- Barcode and QR reader
- External temperature and humidity sensor
- SD card and mains adapter
Downloads
Accessories
Barcode labels for teraohmmeter EP-RM 4000, 50 x 25 mm, 100 pcs on roll
Item C-212 4000-B
