Extraction arm DN50, 2 joints, 430 mm, black, wall and ceiling mounting - Alsident 50-27-3-050

When there is no room for a bracket on the bench, the arm comes from above or from the wall. The 50-27-3-050 extraction arm from Alsident System 50 is mounted on a wall or ceiling and reaches 430 mm with 2 joints. Designed for 45 to 85 m³/h (65 m³/h nominal), it removes vapours and particles where they are generated while the whole work surface stays usable. The black polypropylene joints combine the anodised aluminium tube with a discreet look.

Benefits

• Clear work surface thanks to wall or ceiling mounting
• Self-supporting, internal springs and threaded rods hold any position
• Dismantling and cleaning without tools
• Springs, threaded rods and thumb screws in acid-resistant AISI 316L stainless steel
• Maintenance-free polyethylene O-rings

Specifications

Applications

• Treatment chairs in dental clinics and chiropody practices
• Pharmacies and laboratories with limited bench space
• Assembly and soldering stations in electronics with wall connection

Compatibility and scope of delivery

• Supplied without hood and bracket, order both separately
• Open wall bracket in black 2-195-050 or base box in black version (-050)
• Hoods with suffix -050 from System 50, suction nozzle 1-5021 recommended
• Cover flange 4-200-200 for base boxes in suspended ceilings
