ESD extraction arm DN50, 2 joints, 745 mm, table mount - Alsident 50-57-1-6

The ESD extraction arm 50-57-1-6 is built for electrostatic protected areas: tubes in TCP passivated aluminium and joints in conductive polypropylene discharge to earth through the supplied 1 MΩ grounding cable. With 745 mm reach and 2 joints it captures soldering fumes right at the source, and System 50 is rated for 45 to 85 m³/h.

Benefits

• 745 mm reach with 2 joints: hood positioned across a single workstation, measured from the centre of the hood opening
• Self-supporting design with threaded rods and springs inside the tube: easy to move and to bring to the source
• Tested for ESD areas to IEC 61340-5-1, grounded through a cable with 1 MΩ safety resistor
• Maintenance is limited to cleaning as needed, and the arm comes apart without tools
• Quick to fit on the bench with a table bracket or U-profile

Specifications

Applications

• ESD protected areas (EPA) in electronics production
• Soldering and rework stations for sensitive assemblies
• Laboratories with ESD requirements

Compatibility and scope of delivery

• System 50 AS hoods, e.g. nozzle 1-5021-6 or round hood 1-5024-6
• Protective grid 5-16-6 against foreign objects being drawn in
• Table bracket 2-5010 (white) or 2-5010-050 (black), alternatively U-profile 30-50-5
• Scope of delivery: extraction arm with grounding cable, hood and bracket are ordered separately
