ESD extraction arm DN75, 2 joints, 750 mm, black, table mounting - Alsident 75-55-1-6

This antistatic extraction arm from Alsident System 75 removes vapours, fumes and particles at the point of origin, before they spread into the room air. In electronics production it captures soldering fumes and vapours inside the ESD protected area without the arm building up static charge. Fitted on a table bracket or U-profile, the arm sits right at the workstation, and the 750 mm reach suits a compact station where the hood stays close to the source. Tubes and joints are made of black conductive polypropylene, and an earthing cable is supplied.

Benefits

• Self-supporting design: threaded rods and springs sit inside the arm, so the hood is easy to position at the source
• Dismantled without tools in a few steps, maintenance is limited to cleaning as needed
• Conductive tubes, joints and O-rings dissipate charges, an earthing cable with 1 MΩ resistor is supplied for ESD areas
• Approved for potentially explosive atmospheres to EN 80079-36 and EN 80079-37, marked Ex II 1 GD

Specifications

Applications

• ESD protected areas in electronics manufacturing
• Potentially explosive atmospheres (ATEX, Ex II 1 GD)
• Laboratories requiring static dissipation

Compatibility and scope of delivery

• Matching System 75 hoods: 1-7524-6 (round Ø200), 1-7535-6 (round Ø385), 1-753324-6 (330 x 240 mm), 1-7525-6 (suction nozzle 250 mm)
• Bracket: table bracket 2-7510 or U-profile 30-75-5
• For ATEX areas the manufacturer recommends brackets in acid-resistant stainless steel
• Guard grille 5-17-6, reducing socket 4-8075 (80/75 mm) or 4-10075 (100/75 mm) to the exhaust duct
• Scope of delivery: extraction arm without hood and bracket, order both separately, earthing cable included
