ESD safety low shoe SL 825 XP blue S1PS SR, SportLine fabric, width 10 - Atlas 69900

Every gram on the foot counts when a shift runs eight hours. The SL 825 XP blue therefore uses a SportLine textile fabric instead of leather and an aluminium toe cap instead of steel, tested to EN ISO 20345 for 200 joules of impact energy and 15 kN of compression. The metal-free XP insert completes class S1PS SR to EN ISO 20345:2022, and to DIN EN 61340-5-1 the resistance stays below 100 MOhm.

What the shoe does on the shop floor

• ESD shoe to DIN EN 61340-5-1. In the person-shoe-floor system the resistance stays below 100 MOhm, so the wearer's charge drains off in a controlled way instead of discharging into a component.
• Aluminium toe cap (alu-tec), tested to EN ISO 20345 for 200 joules of impact energy and 15 kN of compression. Aluminium weighs less than steel and forms no cold bridge across the forefoot.
• Metal-free XP penetration-resistant insert made from aramid fabric. It covers the full sole area, weighs less than a steel midsole and leaves the foot its natural torsion.
• SportLine upper, an air-permeable textile fabric that keeps the shoe light and moves perspiration outwards.
• MPU REBOUND SYSTEM in the sole. It absorbs impact energy at the heel and returns it into the roll-off, which is what counts across eight hours of standing and walking.
• clima-stream concept, which draws moisture out of the shoe interior and balances the temperature.

Technical data

Areas of use

Electronics manufacturing, placement and testing, assembly lines, warehousing and picking in EPA zones, and warm halls where breathability matters.

Standards and conformity

Class S1PS to EN ISO 20345:2022 means closed heel area, antistatic build, energy absorption in the heel and penetration resistance. The trailing S marks the metal-free penetration-resistant insert, tested with the 3.0 mm nail. SR stands for slip resistance on ceramic with glycerine. For the ESD workplace, DIN EN 61340-5-1 is the governing standard. It measures the person-shoe-floor system, and the value has to stay below 100 MOhm. At the lower end the shoe standard caps the resistance at 0.1 MOhm so that the shoe still insulates during work up to 230 V. The antistatic range of the shoe standard itself runs from 0.1 MOhm to 1,000 MOhm.

The shoe is personal protective equipment of category II under PPE Regulation (EU) 2016/425. The model is approved for orthopaedic insoles to DGUV rule 112-191, the marking inside the shoe is what counts. The EU declaration of conformity is provided by the manufacturer ATLAS-Schuhfabrik in Dortmund.

Sizes

The article covers sizes 36 to 49, and each size can be ordered as its own variant. The sales unit is one pair.
