Heavy-duty metal bracket in galvanized steel for Rexroth profile slot 10 systems. Withstands bending moments up to 400 Nm and forces up to 4000 N. Supplied complete with T-bolts, flange nuts, and hexagon nut.

Metal Bracket 103x103x37 mm, Profile Slot 10, ESD-Compatible, Galvanized Steel - Bosch Rexroth 3842564154

Name: Metal Bracket 103x103x37 mm, Profile Slot 10, ESD-Compatible, Galvanized Steel - Bosch Rexroth 3842564154
Brand: Bosch Rexroth
SKU: BRR-3842564154
Price: 18.36 EUR
Availability: InStock

BOSCH REXROTH Original product

Net price (excl. VAT)

€18.36

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item BRR-3842564154

Manufacturer no. 3842564154

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.3842564154

Country of originGermany

Customs tariff number83024900

ConditionNew

Article

BRR-3842564154

Frequently Bought Together

This Item: Metal Bracket 103x103x37 mm, Profile Slot 10, ESD-Compatible, Galvanized Steel - Bosch Rexroth 3842564154
€18.36
Excl. 19% VAT , excl. Shipping Cost
Bracket 40x40 ESD, diecast aluminum, slot 10 - Bosch Rexroth 3842529383
€4.57
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

The 103x103x37 metal bracket creates rigid, ESD-safe connections in Rexroth aluminum profile assemblies. Its flat profile keeps it within the profile contour, making it well suited for machine frames, assembly workstations, and other structural applications where clearance is limited.

High load capacity: bending moment 1 up to 180 Nm, bending moment 2 up to 400 Nm, torsional moment 60 Nm, max. force 4000 N
ESD-compatible - safe for use in electrostatically sensitive environments
Galvanized steel construction for corrosion resistance and long service life
Complete delivery: 4 x T-bolt, 4 x flange nut M8, 1 x hexagon nut ISO4032-M12-8-TZN
Designed for profile slot 10 of the Rexroth aluminum profile system

Technical data

Attribute	Value
Dimensions	103 x 103 x 37 mm
Profile slot	10
Material	Steel, galvanized
Fastening material	Steel, galvanized
ESD	Yes
Bending moment 1	180 Nm
Bending moment 2	400 Nm
Torsional moment	60 Nm
Force Fmax	4000 N
Weight	0.503 kg
Scope of delivery	4 x T-bolt, 4 x flange nut M8, 1 x hexagon nut ISO4032-M12-8-TZN

Information

More Information
Manufacturer Nr.	3842564154
Manufacturer	Bosch Rexroth
Country of Manufacture	Germany
Weight	0.503000
HS-Code	83024900
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
