The HD 2 lift-rotate unit raises the workpiece pallet and turns it to the required orientation. On loop systems without curves it keeps the pallet orientation constant, so the front stays the front. This ESD-capable version rotates 180 degrees at a 40 mm lift and suits workpiece pallets with a 160 mm track width on the TS 2plus system.
Lift-Rotate Unit HD 2 ESD, 160 mm Track Width, 320 mm Length, 180 Degree Rotation, 40 mm Lift - Bosch Rexroth 3842525853
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,907.61
Item
BRR-3842525853
Manufacturer no.
3842525853
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842525853
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842525853
Frequently Bought Together
-
This Item:
€4,907.61
-
Housing element for HD 2/H, 1040 x 1040 mm, 90° - Bosch Rexroth 3842552599
€963.16
-
Housing Element for HD 2/H Conveyor, 240/320, 180° - Bosch Rexroth 3842552602
€531.90
Total price
The HD 2 lift-rotate unit raises the workpiece pallet and turns it to the required orientation. On loop systems without curves it provides a constant pallet orientation, so the front stays the front. Work operations on the HD 2 are permitted without additional applied forces.
- ESD-capable version for handling electrostatically sensitive components
- 180 degree rotation about the Z axis
- 40 mm lift turns the workpiece pallet directly above the conveyor section; for side-mounted components the 90 mm lift version may be required
- fastening material included
Technical data
| Article number | 3842525853 |
| Type | Lift-rotate unit HD 2 |
| ESD | yes |
| Workpiece pallet total weight (mG) | 16 kg |
| Track width in direction of transport (b) | 160 mm |
| Length in direction of transport (lT) | 320 mm |
| Rotation angle (DW) | 180° |
| Lift of WT over conveyor level (h) | 40 mm |
| Max. permitted total mass moment of inertia | 0.65 kgm² |
| Dimension c | 42 mm |
| Dimension d | 42 mm |
| Weight | 22.2 kg |
| Scope of delivery | incl. fastening material |
| Required accessories | Stop gate VE 2/..., M12x1 sensor (sensing range SN 4 mm, not flush-mountable) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842525853 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
