Housing element for HD 2/H, 1200 x 1200 mm, 180° - Bosch Rexroth 3842552630
Datasheet (PDF)
The product may differ from the illustration
Housing element for the HD 2/H transfer system, covering workpiece pallets measuring 1200 x 1200 mm in a 180° configuration. The enclosure protects the unit and surroundings against interference below the conveying level. Protection above the conveying level must be specified separately for each application.

Housing element for HD 2/H, 1200 x 1200 mm, 180° - Bosch Rexroth 3842552630

BOSCH REXROTH Original product
Net price (excl. VAT)
€876.92
Item BRR-3842552630
Manufacturer no. 3842552630
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842552630
Country of originGermany
Customs tariff number73089059
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842552630

The housing element 3842552630 is designed for the Bosch Rexroth HD 2/H transfer system and fits workpiece pallets of 1200 x 1200 mm. It closes off the system below the conveying level, guarding against mechanical impacts and foreign-body ingress to ensure reliable operation. Coverage above the conveying level must be planned individually per application.

  • Precise fit for HD 2/H with 1200 x 1200 mm workpiece pallet size
  • 180° version for straight-line system integration
  • Protection below the conveying level against mechanical and external interference
  • Complements the modular assembly technology portfolio of Bosch Rexroth

Technical data

ParameterValue
Article number3842552630
System seriesHD 2/H
Workpiece pallet length1200 mm
Workpiece pallet width1200 mm
Angle version180°
Weight26.77 kg
More Information
ExecutionTEC
Manufacturer Nr.3842552630
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.009900
HS-Code73089059
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
